T-2208 - 22 Kanal Profesyonel Digital Mixer
-
$2.065,50
T-2208 - 22 Kanal Profesyonel Digital Mixer
• 22 Input, 16 XLR's, 4 Line, 2 usb
• 12 Outputs, Buses, 2HD FX Processors
• 32 DSP Channels, Gate, PEQ, Camp.
• 6 DCA Groups, Physical metering
• Software Meters, iPad Reote Control Easy Install Matrix
| Electronically balanced | |
| Frequency Response to direct Output | 20Hz-20KHz at 0dBu ±1.5dB |
| Distortion (THD&N) to Main Output | <0.01% at OdBu 1KHz |
| SNR (Signal to Noise Ratio) | 104dB |
| Maximum Input Level | +22dBu |
| Phantom Power (+/-3V) | +48VDC |
| Line inputs | Unbalanced |
| Frequency Response to direct Output | 20Hz-20KHz at 0dBu ±1.5dB |
| Distortion (THD&N) to Main Output | <0.01 % at 0dBu 1KHz |
| Gain | -15dBu ~ +35dBu |
| Maximum Input Level (Gain at OdBu) | +20dBu |
| 17-18/19-20 stereo inputs | Balanced (2 stereo pair) |
| Frequency Response to Main Output | 20Hz~20KHz at +4dBu ±1.5dB |
| Distortion (THD&N) to Main Output | <0.01 % at 0dBu 1KHz |
| Gain | -8 to +10dBu |
| Maximum Input Level | +22dBu |
| Tape L/R input/USB | 20Hz-20KHz at +4dBu |
| Frequency Response to Main Output | 20Hz-20KHz at +4dBu ±1.5dB |
| Distortion (THD&N) to Main Output | <0.01 % at 0dBu 1KHz |
| Gain | -8 to + 10dBu |
| Maximum Input Level | +22dBu |
| Main Outputs | |
| Maximum Output Level | +20dBu |
| AUX1-8 Outputs | |
| Maximum Output Level | +20dBu |
| Control Room Outputs | |
| Maximum Output Level | +20dBu |
| System Crosstalk | -87dBu |
| Input to Output (at +4dBu 1 KHz) | |
| Adjacent Channels (at +4dBu 1 KHz) | -86dBu |
| Noise (Bus noise) | -90dBu |
| Noise Gate | |
| Threshold Range | -84dBu - 0dB |
| Attack time | 0.5mS ~ 200mS |
| Release time | 5mS ~ 2S |
| Compressor | |
| Threshold Range | -30dBu -+20dB |
| Attack time | 10mS ~ 150mS |
| Release time | 10mS-1S |
| Ratio | 1 :1 to 24:1 |
